| generall network interface issues |
|
Posted by: Sandman01 - 04-28-2016, 04:31 AM - Forum: Getting Started
- Replies (9)
|
 |
Hi
My name is Mario and I'm new to the Pine64 but I'm familiar with
2 RaspberryPi1 B
2 RaspberryPi2 B
1 RaspberryPi3 B
1 LattePanda (x86 dev board)
I received my The PINE A64+ w/ 2GB SDRAM 2 weeks ago and I'm still unable to use the Pine because of the overall stability,... issues.
1st the pine needs a power supply >= 2A
Ok mine has 2A and it works, my second one with (nominal rated) 2,4A won't work stable
I managed to get the images booting (most of them) but all images are unable to connect to my network (dhcp server running on my router for IPv4)
also my additionally order WiFi module creates bootloops on all images exept arch linux which do not detect the module (so also no networ)
Is there an test I can process to check if ther is something wrong with my whole board?
I prefer ubuntu linux images to make my test and ther the eth0 interface is shown
however no inet (IPv4) network address if assigned to it
The ethernet cable and the router work like a charm because (I use the cable also for my other dev boards)
Also tried to set the ip static in
Code: /etc/network/interfaces
but without luck, tha adress is assinged correctly but no connection could be astableshed by tesing to ping my router (internally activated to answer on pings)
would be nice if someone could give me a few opportunities what I can test to get any network up and running because without network the Pine is useless (no updates, Android,....)
BTW:
For my boot loops with the WiFi module I will make an additional battery pack that shall support my power supply or test an supply that is pluged in over the RasPi connector because Power supplies for micro USB are mostly limited to max 2,4A (due to standard USB cable requirements limited crosssection)
best regards,
Mario Holzinger
|
|
|
|
| Bluetooth not working |
|
Posted by: reesh95 - 04-28-2016, 01:29 AM - Forum: General Discussion on PINE A64(+)
- No Replies
|
|
Hi,
i have run into a problem where the ubuntu image is not detecting the bluetooth adapter . I had ordered the stock wifi + BT module that fits into the pine64 and wifi is working properly. what can i do to solve this ?
Thanks in advance
|
|
|
|
| No sound. Need help to resolve |
|
Posted by: jsyu - 04-27-2016, 11:17 PM - Forum: General Discussion on PINE A64(+)
- Replies (4)
|
|
Received my 2G board yesterday. Tested with Unbuntu, Arch Linux and Android, all works fine except there is no audio output from on-board audio plug. Don't know whether this a hardware flaw or a software issue. Should I send it back for RMA or there is anything I can do to fix? Please advise.
|
|
|
|
| using dd to clone image |
|
Posted by: jproffer - 04-27-2016, 06:29 PM - Forum: Archlinux
- Replies (2)
|
 |
Hi all,
I'm trying to burn arch to a microsd via
Code: dd if=arch-pine64-bspkernel-20160403-1.img of=/dev/sdg1 bs=1M
the image burns fine, but once i eject/reinsert the microsd, my OS cannot mount or recognize the FS on the microsd. Any help?
I run arch linux with XFCE here, and my kernel supports all the common FS's up to ext4fs, reiserfs, and ntfs.
|
|
|
|
| Media server |
|
Posted by: montero65 - 04-27-2016, 02:20 PM - Forum: Pine A64 Projects, Ideas and Tutorials
- Replies (3)
|
 |
My plan is to set up my Pine to use as a media server, mostly for video. I've been digitizing my DVD collection onto a 2TB external hard drive, which I would plug into the USB port.
I do have a question though. I bought 2 boards, both with the wi-fi/bluetooth chips. If I have one board plugged into my TV out front, with the hard drive attached, could I use the 2nd board, connecting over the wi-fi, to access the data on the hard drive from another room? Basically, wondering if I can have the 2nd board setup in my bedroom and still access the movies on the hard drive connected to the 1st board, without having to move the hard drive between boards.
I plan to run this on Android, but wondering if it will be the best OS for me for a media server? Is there a different OS that would work better? I don't really know what all the OS's are, so if someone else is doing a media server, I'd be interested to know how you are setting it up. Thanks!
|
|
|
|
| Use Audiojack instead of HDMI audio |
|
Posted by: pictus - 04-27-2016, 12:45 PM - Forum: Pine A64 Hardware, Accessories and POT
- Replies (55)
|
|
Hi,
i installed longsleep´s Ubuntu and added xubuntu-desktop. i can´t find an option to enable the audiojack on the board, it always uses the HDMI audio.
Running
Displays:
Code: Card #0
Name: alsa_card.platform-sound.7
Driver: module-alsa-card.c
Owner Module: 6
Properties:
alsa.card = "0"
alsa.card_name = "sndhdmi"
alsa.long_card_name = "sndhdmi"
device.bus_path = "platform-sound.7"
sysfs.path = "/devices/soc.0/sound.7/sound/card0"
device.string = "0"
device.description = "sndhdmi"
module-udev-detect.discovered = "1"
device.icon_name = "audio-card"
Profiles:
output:analog-mono: Analog Mono Output (sinks: 1, sources: 0, priority: 200, available: yes)
output:analog-stereo: Analog Stereo Output (sinks: 1, sources: 0, priority: 6000, available: yes)
off: Off (sinks: 0, sources: 0, priority: 0, available: yes)
Active Profile: output:analog-stereo
Ports:
analog-output: Analog Output (priority: 9900, latency offset: 0 usec)
Part of profile(s): output:analog-mono, output:analog-stereo
is it possible to enable the Analog Audio output through the audiojack?
----------------------------------------------------------------------------------------------
EDIT: it works, big thanks goes to longsleep for his great support
Update to latest Kernel Version! (i use 3.10.101-0-pine64-longsleep-39)
Step by Step guide:
Code: cat <<EOF >/etc/modules-load.d/pine64-audiojack.conf
sunxi_codec
sunxi_i2s
sunxi_sndcodec
EOF
Download this file https://github.com/longsleep/build-pine6...ound.state and put it under (thanks longsleep)
Code: /var/lib/alsa/asound.state
Reboot, now it works!
I use a desktop enviroment and can switch between output devices in Soundsettings (PulseAudio Volume Control - pavucontrol)
|
|
|
|
| PiVPN: Simplest setup of OpenVPN |
|
Posted by: Rocky-IV - 04-27-2016, 11:39 AM - Forum: Pine A64 Projects, Ideas and Tutorials
- Replies (3)
|
 |
Good Day
Subject OpenVPN
Since this project is setup for the RasberryPi, I'm suggesting that Pine A64 adopt this also if at all possible.
PiVPN: Simplest setup of OpenVPN
http://www.pivpn.io
POLL is Essential for Action! - Please Complete
Lets see if we get enough interest from our community and forums members.
I'm in total agreement to contact the the Dev of PiVPN.
Thanks
Rocky-IV
|
|
|
|
|
![[Image: IMG_1080.JPG]](https://wlvac.com/IMG_1080.JPG)
![[Image: IMG_1081.JPG]](https://wlvac.com/IMG_1081.JPG)
