  Windows 10???
Posted by: dcmorley - 08-25-2017, 06:53 AM - Forum: News - Replies (16)

Does anyone know if the Pine64 is on the list of the supported ARM CPU's reportedly supported in the upcoming Windows 10 release?


  Compile Gstreamer on ROCK64
Posted by: silverknight - 08-25-2017, 05:59 AM - Forum: Linux on Rock64 - Replies (3)

I tried to compile https://github.com/rockchip-linux/gstreamer-rockchip but failed. Anyone know how to ?


  Case Mod Opening for Serial Console Slider Switch
Posted by: MarkHaysHarris777 - 08-25-2017, 01:59 AM - Forum: Pinebook Hardware and Accessories - Replies (1)

Greetings,

I've been working on a Pinebook case mod which will safely expose the serial console slider switch on the main board without dismantling the Pinebook every time;  that was getting old fast-- ten tiny little screws ( its a miracle I have lost none of them yet ) !



The pic above is the slider switch;  look to the upper left of the pic and you'll see the pencil marks for the proposed dremel styrene work. The switch is in from the side 1.1 - 1.7 cm  and down from the back 8.1 - 8.2 cm.



I chose a 1.0mm carbonide cutting wheel for the dremel tool; do this from the underneath side cause it makes one dandy mess, but it cleans up nicely with a sharp modeling knife and a nail file.  Tip:  practice on another piece of styrene first ;  dremels take some getting used to.



This is the case opening after cleanup;  there is still ample protection, things will stay out of there, but the switch may be accessed easily.



Final pic is my high intensity 9 LED flashlight illuminating the slider switch inside the Pinebook case.  I use a simple slider switch access tool (toothpic) and voilà  !

Shy


  Does snapchat work on pine64 with android?
Posted by: user875545 - 08-25-2017, 01:04 AM - Forum: Android on Pine A64(+) - Replies (1)

I know snapchat despises anything but 'real' ™ factory default phones so will it work with this or not?

I would like to get one of these sbcs for mobile programming work instead of buying a smartphone since they don't have the government surveillance crap hardwired into them like phones do but if I need to run snapchat and if it wouldn't work then I would have to maybe get over my paranoid delusions and buy a normal phone for this work Smile.

So has anyone run snapchat successfully on it or not?


Video Kernel Panic on Rock64 linux
Posted by: tanisou - 08-24-2017, 10:30 PM - Forum: General Discussion on ROCK64 - Replies (15)

About My Rock64 occurred kernel panic.

I bought four Rock64 board.
2 of 4GB model,2 of 2GB model.
Other 3 boards works well.
One of 4GB model occurrd this problem every time.
Im using newest xenial-minimum and xenial-mate on MicroSD.
Power supply to GPIO 5V and GND by iPad Pro's 5V 2.4A charger.
But other 3 board work well under same MicroSD,OS image,charger.
So I think comatibility problem(or initial failure?)

movie:xenial minimum on microSD
pictureConfusedame(https://drive.google.com/file/d/0B58MjMV...sp=sharing)
I know how to fix this problem.
Sorry my bad english and Thank you forum member





  Ephemeral RTC Settings
Posted by: Siliconserf - 08-24-2017, 06:39 PM - Forum: Linux on Pinebook - No Replies

OK, I'm  sure there is something I'm not doing right, but the RTC has me stumped. I use the access point in the upper right of the Mate desktop to set the RTC to use my time zone and report time in 12, instead of 24 hour format. I do this as a user with Admin privileges. And the clock changes appropriately...until the next boot, whereupon I see that it has forgotten the settings and has gone back to defaults. The menus are very explicit about setting the system clock options. So what have I missed?


Information Solved - Resize Root Filesystem (Xenial)
Posted by: aussiemate - 08-24-2017, 05:38 PM - Forum: Linux on Rock64 - Replies (4)

This is for those less familiar with Linux, or running Linux from an SD card.
When you flash Ubuntu Xenial onto an SD card, the root filesystem size is only big enough to fit the operating system.
This is intentional; to keep the size of the image file as small as possible, making it quicker to download and flash to any size SD card (within reason).
After flashing the sd card and booting up for the first time, log in and do the following to expand the root filesystem by following these instructions.
There's a lot of code below, but the whole process took me less than 2 minutes, and you should be able to safely accept the default response to all prompts.

1. Fix the partition table to reflect the size of the SD card:

Code:
rock64@rock64:~$ sudo parted -l
Warning: Not all of the space available to /dev/mmcblk1 appears to be used, you
can fix the GPT to use all of the space (an extra 60332032 blocks) or continue
with the current setting?
Fix/Ignore? F
Model: SD 5&DRP (sd/mmc)
Disk /dev/mmcblk1: 32.1GB
Sector size (logical/physical): 512B/512B
Partition Table: gpt
Disk Flags:

Number  Start   End     Size    File system  Name       Flags
1      32.8kB  4129kB  4096kB               loader1
2      4129kB  4194kB  65.5kB               reserved1
3      4194kB  8389kB  4194kB               reserved2
4      8389kB  12.6MB  4194kB               loader2
5      12.6MB  16.8MB  4194kB               atf
6      16.8MB  134MB   117MB   fat16        boot       legacy_boot, msftdata
7      134MB   1208MB  1074MB  ext4         root

2. Increase the root partition size:
Code:
rock64@rock64:~$ sudo fdisk /dev/mmcblk1

Welcome to fdisk (util-linux 2.27.1).
Changes will remain in memory only, until you decide to write them.
Be careful before using the write command.


Command (m for help): p
Disk /dev/mmcblk1: 29.9 GiB, 32099008512 bytes, 62693376 sectors
Units: sectors of 1 * 512 = 512 bytes
Sector size (logical/physical): 512 bytes / 512 bytes
I/O size (minimum/optimal): 512 bytes / 512 bytes
Disklabel type: gpt
Disk identifier: 062EE0ED-2FD5-4D89-B424-771CB4465BD4

Device          Start     End Sectors  Size Type
/dev/mmcblk1p1     64    8063    8000  3.9M Linux filesystem
/dev/mmcblk1p2   8064    8191     128   64K Linux filesystem
/dev/mmcblk1p3   8192   16383    8192    4M Linux filesystem
/dev/mmcblk1p4  16384   24575    8192    4M Linux filesystem
/dev/mmcblk1p5  24576   32767    8192    4M Linux filesystem
/dev/mmcblk1p6  32768  262143  229376  112M Microsoft basic data
/dev/mmcblk1p7 262144 2359295 2097152    1G Linux filesystem

Command (m for help): d
Partition number (1-7, default 7):

Partition 7 has been deleted.

Command (m for help): n
Partition number (7-128, default 7):
First sector (262144-62693342, default 262144):
Last sector, +sectors or +size{K,M,G,T,P} (262144-62693342, default 62693342):

Created a new partition 7 of type 'Linux filesystem' and of size 29.8 GiB.

Command (m for help): w
The partition table has been altered.
Calling ioctl() to re-read partition table.
Re-reading the partition table failed.: Device or resource busy

The kernel still uses the old table. The new table will be used at the next reboot or after you run partprobe(8) or kpartx(8).

3. Tell the kernel the partition table has changed:
Code:
rock64@rock64:~$ sudo partprobe /dev/mmcblk1


4. Resize the root filesystem to fill the partition:
Code:
rock64@rock64:~$ sudo resize2fs /dev/mmcblk1p7
resize2fs 1.42.13 (17-May-2015)
Filesystem at /dev/mmcblk1p7 is mounted on /; on-line resizing required
old_desc_blocks = 1, new_desc_blocks = 2
The filesystem on /dev/mmcblk1p7 is now 7803899 (4k) blocks long.

rock64@rock64:~$ df -h
Filesystem      Size  Used Avail Use% Mounted on
udev            459M     0  459M   0% /dev
tmpfs            93M  3.9M   89M   5% /run
/dev/mmcblk1p7   30G  769M   28G   3% /
tmpfs           462M     0  462M   0% /dev/shm
tmpfs           5.0M  4.0K  5.0M   1% /run/lock
tmpfs           462M     0  462M   0% /sys/fs/cgroup
/dev/mmcblk1p6  100M   22M   79M  22% /boot/efi

Reboot and you're done!
...but don't forget to change the default password from rock64  Rolleyes


Bug Rock64 Boot-up Bug with Serial Console Cable
Posted by: MarkHaysHarris777 - 08-24-2017, 04:33 PM - Forum: Rock64 Hardware and Accessories - Replies (1)

Greetings,

The Rock64 often will not boot-up with a serial console connected to the console uart pins (6, 8, & 10).

Symptom:  lights come on, nothing happens at all.

Solution:  unplug the Tx line coming in on pin(10) prior to applying power for boot-up.




The Tx line often (if not always) has 3v3 on it when the other end is powered up, even in the idle state.  This voltage present on pin(10) of the Rock64 prevents it from booting, sadly.  I have reliably verified that unplugging the Tx line in on pin(10) of the Rock64 will allow the boot-up to start...  as it boots up , carefully plug the Tx line back onto pin(10).

Also noticed that the Tx line (if left connected to pin[10] on Rock64 power-down) will back-feed into the board, which will dimly light the red LED (small glow) !  This back-feed is preventing boot-up.

Fortunately the serial console monitor does not need this line connected to monitor as long as it has the Rx connection and a good ground,  so unplugging the line from pin(10) does not prevent monitoring the boot-up messages on the serial console.

Note:   This problem occurs on both of my boards;  dev board pre production, and the production master-piece which came last week !

Note:   At this point I don't know if the current draw on the Tx line might damage the monitor ; currently I'm using my PineA64 desk machine as the serial monitor for my Rock64 boards.



  Q4OS Pinebook Questions
Posted by: StewB - 08-24-2017, 03:53 PM - Forum: Linux on Pine A64(+) - No Replies

Nice install of Q4OS to microSD and transferred to the Pinebook internal drive.

What is the proper procedure to log into Wireless? (I see 2 connections: waan0 and waan1)
Will the miniHDMI work?

Thanks, Stew


  CAD drawings of Rock64
Posted by: TeaPack - 08-24-2017, 02:38 PM - Forum: Rock64 Hardware and Accessories - Replies (7)

Hi everyone =) I just made first version of CAD drawings of Rock64, heights of chips are not precise for making multi chip heatsinks, but I'll fix it during next week, maybe with all-in-one masive AL heatsink...

ver. 1  - All possible files available on my github ( https://github.com/TeaPackCZ/Rock64_drawings ) more info at Full description ver 1
ver. 2  - Added DAC board and pictures of models, more info at More info about ver. 2

[Image: 1744404_9489a23e92496f06bb62.png]

[Image: 1744403_4901d252463b1f3136d4.png]

____________________
Note: I'll edit this post to correspond with actual state...
