Network Speed
#14
Here is the SMB performance on my Rock64 tested using a 5GB file.


[Image: attachment.php?aid=1069]
Copying from Rock64 (conventional disk, EXT4) to Win 10 laptop (SSD)

[Image: attachment.php?aid=1070]

Copying from Win 10 laptop (SSD) to Rock64 (conventional disk, EXT4)

Here is my FSTAB file:

Code:
rock64@rock64:~$ cat /etc/fstab
LABEL=boot /boot/efi vfat defaults 0 1
UUID="c56c18b8-5004-4ea6-*censored*" /public  ext4 nofail,noatime 0 2
UUID="ca764a03-db3d-49bc-*censored*" /public3 ext4 nofail,noatime 0 0

USB info:
Code:
rock64@rock64:~$ lsusb
Bus 005 Device 003: ID 152d:0578 JMicron Technology Corp. / JMicron USA Technology Corp.
Bus 005 Device 002: ID 2109:0812 VIA Labs, Inc. VL812 Hub
Bus 005 Device 001: ID 1d6b:0003 Linux Foundation 3.0 root hub
Bus 004 Device 003: ID 1058:0827 Western Digital Technologies, Inc.
Bus 004 Device 002: ID 2109:2812 VIA Labs, Inc. VL812 Hub
Bus 004 Device 001: ID 1d6b:0002 Linux Foundation 2.0 root hub
Bus 003 Device 001: ID 1d6b:0001 Linux Foundation 1.1 root hub
Bus 002 Device 001: ID 1d6b:0002 Linux Foundation 2.0 root hub
Bus 001 Device 001: ID 1d6b:0002 Linux Foundation 2.0 root hub
rock64@rock64:~$ lsusb -t
/:  Bus 05.Port 1: Dev 1, Class=root_hub, Driver=xhci-hcd/1p, 5000M
    |__ Port 1: Dev 2, If 0, Class=Hub, Driver=hub/4p, 5000M
        |__ Port 2: Dev 3, If 0, Class=Mass Storage, Driver=uas, 5000M
/:  Bus 04.Port 1: Dev 1, Class=root_hub, Driver=xhci-hcd/1p, 480M
    |__ Port 1: Dev 2, If 0, Class=Hub, Driver=hub/4p, 480M
        |__ Port 3: Dev 3, If 0, Class=Mass Storage, Driver=usb-storage, 480M
/:  Bus 03.Port 1: Dev 1, Class=root_hub, Driver=ohci-platform/1p, 12M
/:  Bus 02.Port 1: Dev 1, Class=root_hub, Driver=ehci-platform/1p, 480M
/:  Bus 01.Port 1: Dev 1, Class=root_hub, Driver=dwc2/1p, 480M
